Philips 36W yellow Tube

TL-D Colored 36W Yellow 1SL/25 This TL-D lamp (tube diameter 26 mm) helps to create special effects and atmospheres or attract attention by using red, green, blue and yellow light. Apart from using the specific colors, it is also possible to mix the colors to create white light. This lamp offers a high light output, thanks to the use of basic powders. Application areas include shops and showrooms, bars and restaurants, demonstration areas, sign lighting and entertainment stores.

Warnings and Safety • A lamp breaking is extremely unlikely to have any impact on your health. If a lamp breaks, ventilate the room for 30 minutes and remove the parts, preferably with gloves. Put them in a sealed plastic bag and take it to your local waste facilities for recycling. Do not use a vacuum cleaner.

Specifications

General information



Cap-Base	G13  [ Medium Bi-Pin Fluorescent]
Life To 10% Failures (Nom)	12000 h

Life to 50% Failures (Nom)

15000 h



Light technical



Color Code	160
Luminous Flux (Nom)	1580 lm
Luminous Flux (Rated) (Nom)	1580 lm

Color Designation	Yellow
LLMF 2000 h Rated	85 %



Operating and electrical



Power (Nom)	36.0 W
Lamp Current (Nom)	0.440 A

Voltage (Nom)

103 V



Temperature



Design Temperature (Nom)

25 °C



Controls and dimming



Dimmable

Yes



Mechanical and housing



Bulb Shape

T8  [ 26 mm (T8)]



Approval and application



Mercury (Hg) Content (Nom)

13.0 mg

Energy Consumption kWh/1000 h

44 kWh



Product data



Full product code	871150072751040
Order product name	TL-D Colored 36W Yellow 1SL/25
EAN/UPC - Product	8711500727510
Order code	928048501605
Numerator - Quantity Per Pack	1

Numerator - Packs per outer box	25
Material Nr. (12NC)	928048501605
Net Weight (Piece)	135.000 g
